Die einzige kostenfreie Lösung für Continental MCM und ACM

Flex Version 6.27.0.0 bereit

Programmieren Sie im OBD-Full-, Bench- und Boot-Modus die Motorsteuergeräte Continental MCM2, MCM 2.1 und im Bench-Modus die AdBlue-Steuergeräte ACM2.1, ACM2.2, die in den gängigsten Mercedes-Lastwagen und Mercedes-Bussen installiert sind.

Flex hat nun seine Lösung für die Arbeit an Mercedes-LKWs und -Bussen kostenlos zur Verfügung gestellt, mit besonderem Augenmerk auf:

• MCM2.1 D1 OBD Full, Bench und Boot
• MCM2.1 D2 OBD Voll, Bench und Boot
• MCM2.1 D3 OBD komplett, Bench und Boot
• MCM2.1 D4 OBD voll, Bench und Boot

• MCM2.1 D5 OBD voll, Bench und Boot

• MCM2 D3.1 OBD voll, Bench und Boot
• MCM2 D3.2 OBD voll, Bench und Boot
• ACM2.1 D1 Bench
• ACM2.1 D2 Bench
• ACM2.1 D3 Bench
• ACM2.2 D2 Bench

Das Besondere an diesen Protokollen ist, dass bei der Programmierung keine Patches angewendet werden, so dass die Garantie Ihres Fahrzeugs niemals erlischt. Es reicht also aus, das ursprüngliche Full-Backup der Steuergeräte zu schreiben, um den Originalzustand wiederherzustellen.

Mit den neuen MCM- und ACM-Protokollen können Sie über die OBD-Buchse und im Bench-Modus arbeiten, ohne das Gerät öffnen zu müssen.

Darüber hinaus sind Mappacks für die Modifikation von MCM2-Steuergeräten auf StageX verfügbar.

Hier sind einige der unterstützten Fahrzeuge:

• Mercedes Lkw Actros 1851 12.8L OM471LA 510HP
• Mercedes Lkw Arocs 1843 10.7L OM470 428HP
• Mercedes Lkw Antos 2532 7.7L OM936 315HP
• Mercedes Bus Citaro C2 10,7L OM470 394PS
• Mercedes Bus Tourismo RHD 12,8L OM471LA 428PS
• Setra S515 HDH 12,8L OM471LA 470PS
• Freightliner Cascadia DD15 14.8L Detroit DD15 530HP

Die neuen Protokolle sind für die folgenden Softwarepakete verfügbar:

OBD

• FLS0.1M – SW Flex ECU (PKW, Transporter, Motorrad) OBD + Bench Master
• FLS0.1S – SW Flex ECU (Auto, Lieferwagen, Motorrad) OBD + Bench Slave
• FLS0.5M – Flex Voll-SW-Paket Master
• FLS0.5S – Flex Voll-SW-Paket Slave

Für die Programmierung in OBD Full müssen Sie das FLX2.65 Kabel unter www.magicmotorsport.shop oder über LINK TICKET kaufen

BENCH

• FLS0.1M – SW Flex ECU (Auto, Lieferwagen, Fahrrad) OBD + Bench Master
• FLS0.1S – SW Flex ECU (Auto, Lieferwagen, Motorrad) OBD + Bench Slave
• FLS0.5M – Flex Voll-SW-Paket Master
• FLS0.5S – Flex Volles SW-Paket Slave
• FLS0.10M – Flex SW Infineon TC17xx / TCxxx Master
• FLS0.10S – Flex Infineon TC17xx / TCxxx Slave SW

BOOT

• FLS0.5M – Flex Volles SW-Paket Master
• FLS0.5S – Flex Volles SW-Paket Slave
• FLS0.10M – SW Flex Infineon TC17xx / TCxxx Master
• FLS0.10S – Flex Infineon TC17xx / TCxxx Slave SW

Neue Protokolle hinzugefügt:

(OBD Full)

• Mercedes Trucks/Bus Continental MCM2 D3.1 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2 D3.2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D1 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D2 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D3 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D4 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D5 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup

Read time: ~ 1.30 minutes  Write time: ~ 2 minutes

(Bench)

• Mercedes Trucks/Bus Continental MCM2 D3.1 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2 D3.2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D1 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D2 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D3 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D4 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D5 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.1 D1 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.1 D2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.1 D3 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.2 D2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup

Read time: ~ 1.30 minutes  Write time: ~ 2 minutes

(Boot)

• Mercedes Trucks/Bus Continental MCM2 D3.1 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks Continental MCM2 D3.2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D1 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D2 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D3 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D4 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D5 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup

Read time: ~ 1.30 minutes  Write time: ~ 2 minutes

Klicken Sie hier, um die vollständige Liste der unterstützten Fahrzeuge zu sehen.
